發動機
Engine
|
發動機型號Engine model
|
190F
|
|
|
發動機類型 Engine type
|
單缸,4沖程,OHV25度傾斜,強制風冷Single cylinder, 4 stroke, OHV250, forced air-cooled
|
|
|
缸徑×行程 Bore× stroke
|
90×66 mm
|
|
|
排量 Displacement
|
420ml
|
|
|
啟動系統 Starting system
|
手拉反沖起動 Recoil start
|
|
|
點火系統 Ignition system
|
晶體管無觸點點火 Non-contact transistor
|
|
|
油箱容積 Fuel tank capacity
|
25 L
|
|
|
燃油消耗量 Fuel consumption
|
2.7L/hr
|
|
|
50%負荷持續工作時間
50% load continuous running time
|
13 h
|
|
|
機油容積 Oil capacity
|
1.1 L
|
|
發電機
Generator
|
額定頻率 Rated frequency
|
50 Hz
|
|
|
額定電壓 Rated voltage
|
380/230 V
|
|
|
額定功率 Rated output
|
6.5KVA
|
|
|
最大功率 Max. Output
|
6.5KVA
|
|
|
電壓調節方式 Voltage regulation
|
自動調壓 Automatically regulation
|
|
|
功率因數 Power factor
|
1.0
|
|
|
整機噪聲 Noise
|
74 dBA
|
|
包裝
Package
|
包裝箱尺寸（長）Length×（寬）Width×（高）Height
|
690mm×520 mm×585 mm=
|
|
|
凈重 N.W.
|
90 kg
|
|
|
附件
|
含輪子和扶手
|
|
|
40英尺集裝箱裝貨數Qty in 40’HQ
|
236 unit
|
