| 項目Type |
機型Item |
Bitmap
|
| 水泵Water pump |
出水管直徑Outlet size(mm) |
50(2'')/38（1.5'） |
| 進水管直徑Inlet size(mm) |
50(2'') |
| 額定轉速Rated speed(rpm) |
3600 |
| 最大流量Displacement(m/h) |
40 |
| 揚程Lift(m) |
65 |
| 吸程Suction(m) |
7 |
| 發動機Engine |
發動機型號Engine model |
170F |
| 排量Displacement(ml) |
196 |
| 最大功率Max. output HPw(kw) |
7.5(4.8)/3600 |
| 燃油容積Oil capacity(L) |
3.6 |
| 缸徑×行程Bore×stroke(mm) |
70×54 |
| 壓縮比Compression ratio |
8.5:1 |
| 機油容積 Oil capacity(L) |
0.6 |
| 發動機形式 Engine type |
OHV250,單缸，4沖程，強制冷風 OHV250,Single cylinder,4-stroke, forced air-cooled |
| 點火方式Ignition system |
無觸點晶體管點火Transistor magneto |
| 啟動方式Starting system |
手拉反沖式 Recoil |
| 尺寸Size |
包裝尺寸Dimensions(mm) |
440×360×360 |
| 凈重/毛重N.W./G.W.(kg) |
26/28 |
